CAM-VDOM Technical Specifications
| Specification | Detail |
| Image Sensor | Sony 1/3" Interline transfer type color CCD |
| Included Lens | 4mm (62° wide) |
| Effective Pixels | 768 x 494 (380K pixels) |
| Scanning System | 525 Lines 2:1 Interlace |
| Scanning Frequency | 15.734KHz(H), 59.94Hz(V) |
| Resolution | 470 TV Lines |
| Shutter Speed | 1/60 ~ 1/100,000 sec |
| S/N Ratio | More than 48dB (AGC off) |
| Sync System | Internal |
| Minimum Illumination | 0.5 Lux at f1.2 |
| White Balance | AWB (auto white balance) |
| Power Supply | DC12V PSU Included (Camera accepts 10.5V~15V) |
| Operating Temperature | 14°F (-10°C) ~ +122°F (+50°C) |
| Operating Humidity | 90% Relative Humidity Maximum |
| Positioning | Pan/Tilt Manually Adjustable |
Sample Image at Medium Resolution (352 x 240)
Sample Image at Full Resolution (704 x 480)
